Variant in Current Transformer: Square CT

The Square CT, is as per its name square in size and is used for earth leakage and earth fault protection. In the Square CT, the three core cable or three single cores of a three phase system pass through the inner diameter of the CT.

Standard Features:
  • Special application CT's are designed & tested as per client requirement / application.
  • As per National / International Standards.
  • Comprehensive measurement of class accuracy.
  • Wide range of current ratings and busbar sizes.
  • Tested on high accuracy Automatic CT test system
Feature Value
Input Specifications
Current Rating 1 A to 6000 A
Rated Sec . Current 5A or 1 A or as required
Test Voltage 3 KVeff , 50 Hz 1 min / as applicable
System Voltage 720 V max
Outer Insulation Resin / Non - flammable Plastic / Tape (PVC or Fiber Glass)
Protection Class IP 65 ( Resin ) / Ip20
Thermal Short Circuit Current ( Ith ) 60 X In
Rated Continuous Thermal Current ( CTC ) 1.2 In

Note: Technical Specifications and illustrations are subject to change arising out of continuous Product Development.
